The NRGence PE6324L eco PDUs are low profile intelligent PDUs that contain 24 AC outlets and are available in various IEC or NEMA socket configurations. The low profile series has a smaller input region on the PDU to provide more installation space for data centers.
The PE6324L eco PDUs offers remote power control with real-time power measurement - allowing you to monitor the power status of devices attached to the PDUs, either at the PDU device or Bank level, from practically any location via a TCP/IP connection. The power status of each outlet can be set individually, allowing users to switch each device On/Off.
NRGence eco PDU supports any 3rd party v1, v2 & v3 SNMP Manager Software and ATEN eco Sensors (eco PDU Manager Software). eco Sensors provides you with an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it.
The PE6324L eco PDUs offers remote power control with real-time power measurement - allowing you to monitor the power status of devices attached to the PDUs, either at the PDU device or Bank level, from practically any location via a TCP/IP connection. The power status of each outlet can be set individually, allowing users to switch each device On/Off.
NRGence eco PDU supports any 3rd party v1, v2 & v3 SNMP Manager Software and ATEN eco Sensors (eco PDU Manager Software). eco Sensors provides you with an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it.
| AC outlet types | C13 coupler,C19 coupler |
| AC outlets quantity | 24 AC outlet(s) |
| Cable length | 1.6 m |
| Certification | CE, CE-LVD |
| Colour of product | Black |
| Dimensions (WxDxH) | 66 x 44 x 1775 mm |
| Ethernet LAN (RJ-45) ports | 1 |
| Input frequency | 50/60 Hz |
| LED indicators | Y |
| Load capacity | 7360 VA |
| Manual | Y |
| Material | Metal |
| Maximum current | 32 A |
| Monitoring | Humidity,Power,Temperature |
| Mounting | vertical |
| Nominal input voltage | 100-240 V |
| Nominal output voltage | 100-240 V |
| Operating relative humidity (H-H) | 0 - 80 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Package depth | 170 mm |
| Package dimensions (WxDxH) | 210 x 170 x 1890 mm |
| Package height | 1890 mm |
| Package weight | 10200 g |
| Package width | 210 mm |
| PDU types | Metered,Switched |
| Power plug | IEC 60309 |
| Power protection features | Overload |
| Rack mounting | 0U |
| RoHS compliance | Y |
| Storage temperature (T-T) | -20 - 60 °C |
| Supported network protocols | TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, NTP, DNS, Auto Sense, Ping, SNMP V1, V2&V3, Telnet |
| Type | Single-phase |
| Weight | 6200 g |
Aten PE6324LG
30A/32A 24-Outlet Metered & Switched Low Profile eco PDU
£934.80
£779.00 Ex. VAT
30A/32A 24-Outlet Metered & Switched Low Profile eco PDU
