Dual mains input

Increases availability by allowing the UPS to be connected to two separate power sources.



Scalable runtime

Allows additional run time to be quickly added as needed.



Hot-swappable batteries

Ensures clean, uninterrupted power to protected equipment while batteries are being replaced



Generator compatible

Ensures clean, uninterrupted power to protected equipment when generator power is used.



Automatic internal bypass

Supplies utility power to the connected loads in the event of a UPS overload condition or fault.



Battery modules connected in parallel

Delivers higher availability through redundant batteries.



User-replaceable batteries

Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)



Battery replacement without tools

Allows quick, easy battery replacement.



Automatic self-test

Periodic battery self-test ensures early detection of a battery that needs to be replaced.



Shippable with modules installed

Enables pre-installation UPS staging and testing and faster installation.



Modular design

Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.



Network manageable

Provides remote management of the UPS over the network.



InfraStruXure Manager Compatible

Enables centralized management via the APC InfraStruXure® Manager.



LCD display

Alpha-Numeric Display which displays system parameters and alarms.



Audible alarms

Provides notification of changing utility power and UPS conditions.



Programmable frequency

Ensures compatibility with different input frequencies.



LED status indicators

Quickly understand unit and power status with visual indicators.



SmartSlot

Customize UPS capabilities with management cards.



Input power factor correction

Minimizes installation costs by enabling the use of smaller generators and cabling.



Temperature-compensated battery charging

Prolongs battery life by regulating the charge voltage according to battery temperature.



Manual maintenance bypass

Reduces installation costs by eliminating the need for an external mechanical bypass.



Intelligent battery management

Maximizes battery performance, life, and reliability through intelligent, precision charging.



Frequency and voltage regulation

Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.



Safety-agency approved

Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals.



Cold-start capable

Provides temporary battery power when the utility power is out.
Battery type VRLA
Certification CE, ISO
Colour of product Black
Dimensions (WxDxH) 559 x 813 x 1499 mm
Input connection type 3PH + N + G
Interface DB-9, RS-232, Smart-Slot
LED indicators Yes
Maximum current 27 A
Noise level 64 dB
Nominal input voltage 400, 304 - 477 V
Operating relative humidity range 0 - 95 %
Operating temperature range (T-T) 0 - 40 °C
Output connections - 3PH + G;
- 3PH + N + G.
Output power 16000 W
Output power capacity (VA) 20000 VA
Output voltage note 380:400/415V 3
Power supply input frequency 47/70 Hz
Source data-sheet Icecat.biz
Storage relative humidity range 0 - 95 %
Typical backup time at full load 5.5 min
Typical backup time at half load 18.3 min
Weight 415000 g

Specific References

EAN13
7313042543620

APC Smart-UPS VT

Smart-UPS VT, 16 kW/20 kVA, 400V, DB-9, RS-232, Smart-Slot
Out of Stock
£8,857.20
Tax excluded
Reference: SUVTP20KH2B4S
