Dual mains input
Increases availability by allowing the UPS to be connected to two separate power sources.
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
Parallel-redundant capable
Power the connected equipment with multiple UPSs to increase system redundancy
Dual mains input
Increases availability by allowing the UPS to be connected to two separate power sources.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Parallel-capacity capable
Increases total power capacity by using multiple UPSs simultaneously.
Advanced electrical features
Excellent power conditioning, very low harmonic distortion through IGBT rectifier, input power factor correction, and high efficiency
Frequency and voltage regulation
Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
Battery technology |
Sealed Lead Acid (VRLA) |
Colour of product |
Silver |
Depth |
838 mm |
Form factor |
Rackmount |
Height |
1491 mm |
Input connection type |
3PH + N + G |
Interface |
DB-9 RS-232, G35T |
Non-operating altitude |
0 - 15000 m |
Operating altitude |
0 - 999.9 m |
Operating relative humidity range |
0 - 95 % |
Operating temperature range (T-T) |
0 - 40 °C |
Output connections |
1x Hard Wire 4-wire (3PH + G)
1x Hard Wire 5-wire (3PH + N + G) |
Output power |
8000 W |
Output power capacity (VA) |
10000 VA |
Output voltage THD |
4 % |
Package dimensions (WxDxH) |
650 x 1062 x 1643 mm |
Package weight |
630 kg |
Safety |
cUL Listed,CSA,CSA C22.2 No. 107.1,ISO 14001,ISO 9001,UL 1778 |
Serial ports quantity |
1 |
Storage relative humidity range |
0 - 95 % |
Storage temperature range (T-T) |
-15 - 45 °C |
Weight |
599.09 kg |
Specific References
- EAN13
- 4712900370041
