Developed specifically to withstand the harshest industrial environments, these switches offer the most flexible and resilient industrial Ethernet products with secure connectivity, simple management and edge application execution.
The Cisco® Industrial Ethernet (IE) 4000 Series delivers Gigabit connectivity to Cisco ruggedized switching portfolio with superior high-bandwidth switching capacity and proven Cisco IOS® Software. The IE 4000 Series provides highly secure access and industry-leading convergence ring protocols to support resilient and scalable networks while adhering to industry compliance requirements.
The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including manufacturing, energy, transportation, smart cities. With improved overall performance, greater bandwidth, advanced security features, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000.
The Cisco IE 4000 can easily be installed. with a GUI based Device Manager, it also offers out-of-the-box industrial usage configuration and simplified manageability to deliver advanced security, data, video, and voice services over industrial networks.
Basic switching RJ-45 Ethernet ports quantity |
12 |
Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
Broadcast storm control |
Y |
Colour of product |
Black |
Combo SFP ports quantity |
4 |
DHCP server |
Y |
Full duplex |
Y |
Link aggregation |
Y |
MAC address filtering |
Y |
MAC address table |
16000 entries |
Multicast support |
Y |
Networking standards |
IEEE 802.1D,IEEE 802.1Q,IEEE 802.3,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
Non-operating altitude |
0 - 12192 m |
Operating altitude |
0 - 3962 m |
Operating relative humidity (H-H) |
5 - 95 % |
Operating temperature (T-T) |
-40 - 70 °C |
Power over Ethernet (PoE) |
Yes |
Power over Ethernet plus (PoE+) ports quantity |
4 |
Quality of Service (QoS) support |
Y |
Rate limiting |
Y |
Security algorithms |
FIPS 140-2,SNMP,SSH |
SSH/SSL support |
Y |
Storage temperature (T-T) |
-40 - 85 °C |
Switch layer |
L2 |
Switch type |
Managed |
VLAN support |
Y |
BPDU filtering/protection |
Y |
Authentication |
MAC-based authentication |
