Networking administrators managing busy venues must understand how visitors longed for WiFi and how challenging it is to meet the demands within limited budgets.
Zyxel brings affordable and triple-performance 3x3:3 MU-MIMO access point WAC6303D-S which is built with Smart antenna to mitigate co-channel interference in high-density environment. And its embedded BLE Beacon provides insight into your consumers, WAC6303D-S not only resolves the challenge today it thinks for the ever-growing mobility demands tomorrow.
MU-MIMO, New Definition of Wi-Fi
Stepping up from 802.11ac, the second generation Wave 2 technology introduces Multi-User MIMO (MU-MIMO). This is an important WiFi development that enables an AP to communicate with multiple clients at a time offering 300% performance for a 3x3 AP.
Next Generation Transmit Beamforming benefits overall networking
Transmit Beamforming (TxBF) technology is another key to implement reliable high-density Wi-Fi connection. It increases overall network transmission data rates, which benefits not only MU-MIMO clients but also all existing clients.
Optimal Wireless Experience
WAC6303D-S features Smart antenna technology which is proven able to mitigate co-channel interference, and adaptively adjust antenna patterns to fit in high-density application.
Built for Superior performance
The WAC6303D-S is built with a high-efficiency antenna module, premium power amplifiers and low-noise elements delivering superior wireless performance over other Wave 2 access points on the market.
Optimized wireless experience with advanced features
To provide outstanding performance in crowded environment, WAC6303D-S features 3G/4G interference immunity, excellent receive sensitivity and DCS, which enlarge its service coverage for more clients and better quality of connection.
Unified access point- Fits all businesses
Stay standalone mode if you’re a start-up, needing just few APs; convert to controller-managed mode when business grows up, requiring hundreds of APs.
Antenna gain level (max) |
4 dBi |
Cable lock slot |
Y |
Cable lock slot type |
Kensington |
Channel bandwidth |
80 MHz |
Data transfer rate (max) |
1300 Mbit/s |
DC-in jack |
Y |
Depth |
223 mm |
DHCP client |
Y |
Ethernet LAN (RJ-45) ports |
2 |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Height |
39 mm |
Input frequency |
50 / 60 Hz |
Input voltage |
100 - 240 V |
Internal |
N |
MAC address filtering |
Y |
Management protocols |
SNMP v2c/v3 |
Modulation |
16-QAM,64-QAM,256-QAM,BPSK,CCK,DBPSK,DBQSK,QPSK |
Mounting kit |
Y |
Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3au,IEEE 802.3az,IEEE 802.3u |
Operating relative humidity (H-H) |
10 - 90 % |
Operating temperature (T-T) |
-20 - 60 °C |
Output current |
2 A |
Output voltage |
12 V |
Package depth |
247 mm |
Package height |
55 mm |
Package weight |
1040 g |
Package width |
251 mm |
Placement |
Ceiling,Wall |
Power over Ethernet (PoE) |
Yes |
Quality of Service (QoS) support |
Y |
Receiver sensitivity |
-103 dBm |
Security algorithms |
802.1x RADIUS,WPA,WPA-Enterprise,WPA2,WPA2-Enterprise,WPA2-PSK |
Storage relative humidity (H-H) |
10 - 90 % |
Storage temperature (T-T) |
-40 - 70 °C |
Throughput |
1600 Mbps |
VLAN support |
Y |
Weight |
800 g |
Wi-Fi data rate (max) |
1300 Mbit/s |
Width |
211 mm |
2.4 GHz |
Y |
5 GHz |
Y |
Wi-Fi Multimedia (WMM)/(WME) |
Y |
Number of SSID support |
16 |
MIMO |
Y |
MIMO type |
Multi User MIMO |
Product colour |
White |
Maximal-Ratio Combining (MRC) |
Y |
Cyclic Shift Diversity (CSD) |
Y |
Maximum Likelihood Detection (MLD) |
Y |
Specific References
- EAN13
- 4718937594603
ZyXEL WAC6303D-S Data Sheet
