3G | N No No No |
4G | N No No No |
AC adapter included | Y Yes Yes Yes |
Antenna type | External |
Antennas quantity | 8 8 8 8 |
Browser supported | Internet Explorer 11, Microsoft Edge, Chrome 55, Firefox 45, Safari 10 Internet Explorer 11, Microsoft Edge, Chrome 55, Firefox 45, Safari 10 Internet Explorer 11, Microsoft Edge, Chrome 55, Firefox 45, Safari 10 Internet Explorer 11, Microsoft Edge, Chrome 55, Firefox 45, Safari 10 |
Built-in processor | Y Yes Yes Yes |
Cables included | LAN (RJ-45) LAN (RJ-45) LAN (RJ-45) LAN (RJ-45) |
DC-in jack | Y Yes Yes Yes |
Depth | 70 mm |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 5 |
Ethernet LAN data rates | 10,100,1000 Mbit/s 10,100,1000 Mbit/s 10,100,1000 Mbit/s 10,100,1000 Mbit/s |
Firmware upgradeable | Y Yes Yes Yes |
Height | 28.5 mm |
LED indicators | LAN,Power,USB,WAN,WLAN LAN, Power, USB, WAN, WLAN LAN, Power, USB, WAN, WLAN LAN, Power, USB, WAN, WLAN |
Linux operating systems supported | Y Yes Yes Yes |
Mac compatibility | Y Yes Yes Yes |
Mac operating systems supported | Y Yes Yes Yes |
Modulation | 1024-QAM 1024-QAM 1024-QAM 1024-QAM |
Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
On/off switch | Y Yes Yes Yes |
Package depth | 330 mm 330 mm 330 mm 330 mm |
Package height | 141 mm 141 mm 141 mm 141 mm |
Package weight | 2.32 kg 2.32 kg 2.32 kg 2320 g |
Package width | 249 mm 249 mm 249 mm 249 mm |
Power source type | DC |
Processor cores | 4 4 4 4 |
Processor frequency | 2200 MHz 2200 MHz 2200 MHz 2200 MHz |
Product type | Tabletop router Tabletop router Tabletop router Tabletop router |
Quick start guide | Y Yes Yes Yes |
Reset button | Y Yes Yes Yes |
Supported network protocols | IPv6 |
USB port | Y Yes Yes Yes |
Web-based management | Y Yes Yes Yes |
Weight | 1.36 kg |
Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n) 802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n) 802.11a,Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),802.11b,802.11g,Wi-Fi 4 (802.11n) 802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Width | 310 mm |
Windows operating systems supported | Windows 10,Windows 2000,Windows 7,Windows 8,Windows XP Windows 10, Windows 2000, Windows 7, Windows 8, Windows XP Windows 10, Windows 2000, Windows 7, Windows 8, Windows XP Windows 10, Windows 2000, Windows 7, Windows 8, Windows XP |
WPS push button | Y Yes Yes Yes |
Guest access | Y Yes Yes Yes |
Memory card slot(s) | N No No No |
Ethernet LAN interface type | Gigabit Ethernet Gigabit Ethernet Gigabit Ethernet Gigabit Ethernet |
WAN connection type | RJ-45 RJ-45 RJ-45 RJ-45 |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) Wi-Fi 6 (802.11ax) Wi-Fi 6 (802.11ax) Wi-Fi 6 (802.11ax) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) Dual-band (2.4 GHz / 5 GHz) Dual-band (2.4 GHz / 5 GHz) Dual-band (2.4 GHz / 5 GHz) |
Product colour | Black |
Works with Amazon Alexa | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Indication light | Yes |
Master (outer) case width | 289 mm |
Master (outer) case length | 369 mm |
Master (outer) case height | 387 mm |
5G | No |
Harmonized System (HS) code | 85176990 |
Antenna design | External |
