Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Data link protocols | Ethernet |
Data transfer rate | 1000 Mbit/s |
Dimensions (WxDxH) | 285 x 103 x 27 mm |
I/O ports | 16 UTP |
Latency | 100 - 100 Mbps): 40 µs; (1000 - 1000 Mbps): 10 µs |
LED indicators | Link, Power |
MAC address table | 8000 entries |
Maximum data transfer rate | 1 Gbit/s |
Minimum system requirements | Network software (Windows, Linux, Mac OS) |
Networking standards | IEEE 802.1p |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Power consumption (typical) | 25 W |
Power over Ethernet (PoE) | No |
Power requirements | 5 V @ 5 A DC in |
Rack mounting | No |
Safety | CE Mark, Commercial UL listed (UL 1950), C-Tick |
Source data-sheet | Icecat.biz |
Switch type | Unmanaged |
Weight | 900 g |
Harmonized System (HS) code | 85176990 |
