Manage thousands of users with one smart and easy controller.
Exceptional ease-of-use. Best-in-class performance. A full-featured, reliable Wireless LAN architecture. In short, the WC7520 is the smart, easy choice to meet the demands of mid-size organizations with thousands of users.
Reliable, Secure and Scalable Wireless Controller for Mid-sized Businesses, Schools and Hospitals
The NETGEAR ProSAFE® Wireless Controller WC7520 offers a high-performance, fully-featured, yet extremely affordable, Wireless LAN architecture to meet the demands of medium-sized businesses, schools, and hospitals with thousands of users.
Performance
- Seamless L2 and L3 fast roaming provide support for latency-sensitive applications such as video, audio and voice over wireless
- Dynamic RF Management: Automatic controls of AP transmit power and channel allocations ensure coverage by minimizing interferences
- Self-healing Wireless: Automatic WLAN healing after loss of AP or due to RF interferences adapts the power and channel of the other APs around the area
- Load balancing and rate limiting ensure fair bandwidth allocation among all clients for robust wireless connectivity
- Dynamic load balancing of clients across APs is provided based on number of clients per AP, or based on signal strength threshold/data rate threshold of clients per AP
Scalability
- The scalable WC7520 Controller enables businesses to grow their wireless network as needed with a dramatic return on investment: WC7520 scales up to 50 access points (AP) - and up to 150 access points (AP) with stacking
- Support of controller redundancy to maximize reliability
Business Value
- Customer floor maps: Heat maps by wireless band, wireless channel and signal strength allow real-time reporting of the wireless network status
- Redundancy for always-on reliability and peace of mind: N+1 redundancy with failover (one cold redundant Controller for 1, 2 or 3 production Controllers)
- Built to last, the WC7520 Controller is backed by a Lifetime Warranty
Ease of Use
- Configure the MAC address filters, make SSID changes, and change the password for all access points—all from the single WC7520 interface
- Triangulation: Administrators can easily locate known APs, rogue APs, and associated clients on the heat map
- Wireless bundles (for single and dual band APs) for ease of ordering
Dimensions (WxDxH) |
262 x 440 x 43 mm |
Ethernet LAN (RJ-45) ports |
4 |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Flash memory |
8 MB |
Input frequency |
50 - 60 Hz |
Input voltage |
100 - 240 V |
Internal memory |
1024 MB |
Internal memory type |
DDR2 |
LED indicators |
Yes |
Networking standards |
IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
Operating relative humidity (H-H) |
0 - 90 % |
Operating temperature (T-T) |
0 - 45 °C |
Output current |
8 A |
Output voltage |
5 V |
Power LED |
Yes |
Power supply |
13 W |
Rack mounting |
1RU |
Security algorithms |
WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
Storage relative humidity (H-H) |
0 - 95 % |
Storage temperature (T-T) |
-20 - 70 °C |
USB 2.0 ports quantity |
1 |
Weight |
3600 g |
Wi-Fi |
Yes |
Specific References
- EAN13
- 0606449113693
Netgear ProSAFE WC7500 Data Sheet
