Reliable, high-performance, low-latency drive built for data centres.
Kingston’s DC400 SSD offers consistent application performance and low latency over a wide range of read/write workloads, and standard as well as user-adjustable over-provisioning to improve random IOPs performance, making it ideal for data centres. Its enterprise firmware improves latency and helps DC400 deliver consistently low data access times under steady state workloads. It’s available in a Performance-Optimised model with greater IOPs for faster application performance and reduced storage latency and in a Read-Intensive Optimised model that’s factory-tuned for read-intensive workloads. All models deliver enterprise-class reliability with end-to-end data path protection, SmartECC, SmartRefresh and firmware-controlled power loss management. DC400 is backed by legendary pre- and post-sales support and a five-year limited warranty. In addition, there’s Kingston’s web-based Ask an Expert programme, and the SSD Manager toolbox is available in a free, downloadable application.
- Consistently high sustained IOPs and low latency
- Configurable over-provisioning available
- Performance-Optimised model and Read-Intensive model available by special order
- Enterprise-class reliability
- Legendary Kingston support.
Certification |
FCC, VCI |
Colour of product |
Grey |
Component for |
server/workstation |
Data transfer rate |
6 Gbit/s |
Depth |
7 mm |
Downloadable software |
SSD Manager toolbox |
ECC |
Yes |
Height |
100 mm |
Hot-swap |
Yes |
Internal |
Yes |
Latency (read) |
400 µs |
Linux operating systems supported |
Yes |
Mac operating systems supported |
Yes |
Mean time between failures (MTBF) |
2000000 h |
Non-operating vibration |
20 g |
Operating temperature (T-T) |
0 - 70 °C |
Operating vibration |
2.17 G |
Package type |
Blister |
Power consumption (read) |
1.8 W |
Power consumption (standby) |
1.56 W |
Power consumption (write) |
4.86 W |
Random read (4KB) |
78000 IOPS |
Random write (4KB) |
11000 IOPS |
Read speed |
555 MB/s |
Solid-state drive capacity |
960 GB |
Storage temperature (T-T) |
-40 - 85 °C |
TBW rating |
564 |
Weight |
92.34 g |
Width |
69.9 mm |
Windows operating systems supported |
Yes |
Write speed |
520 MB/s |
S.M.A.R.T. support |
Yes |
Solid-state drive interface |
Serial ATA III |
SSD form factor |
2.5" |
Power consumption (average) |
1.6 W |
Maximum read (4KB) |
99000 IOPS |
Maximum write (4KB) |
88000 IOPS |
Specific References
- EAN13
- 0740617254419
Kingston Technology DC400 SSD 960GB Data Sheet
