Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Run-time execution is protected from observation or tampering by any other software (including privileged software) in a system.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Run-time execution is protected from observation or tampering by any other software (including privileged software) in a system.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
| Box | Y |
| Bus type | DMI3 |
| Component for | server/workstation |
| CPU configuration (max) | 1 |
| Embedded options available | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Enhanced Halt State | Y |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel Trusted Execution Technology | N |
| Intel TSX-NI | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Maximum internal memory | 65536 MB |
| Maximum number of PCI Express lanes | 16 |
| On-board graphics adapter | Y |
| On-board graphics adapter model | Intel UHD Graphics 610 |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| PCI Express slots version | 3.0 |
| Processor cache | 4096 KB |
| Processor codename | Coffee Lake |
| Processor cores | 2 |
| Processor family | Intel Pentium |
| Processor frequency | 3.7 GHz |
| Processor lithography | 14 nm |
| Processor model | G5400 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| Product type | 4 |
| Scalability | 1S |
| Supported instruction sets | SSE4.1,SSE4.2 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 54 W |
| Thermal Monitoring Technologies | Y |
| Thermal solution specification | PCG 2015C |
| Tjunction | 100 °C |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory bandwidth supported by processor (max) | 37.5 GB/s |
| Memory channels supported by processor | Dual |
| ECC supported by processor | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Clear Video Technology | Y |
| Processor package size | 37.5 x 37.5 mm |
| On-board graphics adapter outputs supported | DisplayPort,Embedded DisplayPort (eDP),HDMI |
| On-board graphics adapter base frequency | 350 Mhz |
| On-board graphics adapter dynamic frequency (max) | 1050 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.5 |
| Market segment | DT |
| Status | Launched |
| On-board graphics adapter ID | 0x3E90/x93 |
| On-board graphics adapter 4K support | Y |
| On-board graphics adapter refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics adapter refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Product family | Intel Pentium Processor |
| Number of displays supported (on-board graphics) | 3 |
| Intel® vPro™ Technology | N |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Secure Key | Y |
| Intel® OS Guard | N |
| Intel® Turbo Boost Technology | N |
| Intel® Quick Sync Video Technology | Y |
| Processor ARK ID | 129951 |
| Intel® InTru™ 3D Technology | Y |
| Discrete graphics adapter | N |
| Intel® Optane™ Memory Ready | N |
| Cooler included | Y |
| Intel® Memory Protection Extensions (Intel® MPX) | N |
| Intel® Device Protection Technology (Intel® DPT) with Boot Guard | Y |
Specific References
- EAN13
- 0735858367165
Intel G5400
Intel® Pentium® Gold G5400 Processor
(4M Cache, 3.70 GHz)
(4M Cache, 3.70 GHz)
£81.99
£68.33 Ex. VAT
Intel® Pentium® Gold G5400 Processor
