Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® vPro™ Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Box |
No |
Bus type |
QPI |
Compatibility |
Intel R1304RPSSFBN, R1304RPOSHBN, R1208RPOSHOR, P4308RPLSHDR, R1208RPMSHOR, R1304RPMSHOR, S1200V3RPL, S1200V3RPS, S1200V3RPO, S1200V3RPM |
Component for |
server/workstation |
CPU configuration (max) |
1 |
ECC |
Yes |
Enhanced Intel SpeedStep Technology |
Yes |
Execute Disable Bit |
Yes |
Idle States |
Yes |
Intel AES New Instructions |
Yes |
Intel Anti-Theft Technology |
Yes |
Intel FDI Technology |
Yes |
Intel Hyper-Threading Technology |
Yes |
Intel Identity Protection Technology |
Yes |
Intel Quick Sync Video Technology |
Yes |
Intel Secure Key |
Yes |
Intel Smart Cache |
Yes |
Intel Trusted Execution Technology |
Yes |
Intel Virtualization Technology |
VT-d, VT-x |
Intel vPro Technology |
Yes |
Intel VT-x with Extended Page Tables (EPT) |
Yes |
L3 cache |
8 MB |
Memory bandwidth (max) |
25.6 GB/s |
Memory channels |
Dual |
Number of displays supported |
3 |
On-board graphics adapter |
Yes |
PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
Processor boost frequency |
3.9 GHz |
Processor code |
SR14S |
Processor cores |
4 |
Processor family |
Intel Xeon |
Processor frequency |
3.5 GHz |
Processor lithography |
22 nm |
Processor model |
E3-1275V3 |
Processor socket |
Socket H3 (LGA 1150) |
Processor threads |
8 |
Stepping |
C0 |
Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
Supported memory clock speeds |
1333, 1600 MHz |
Thermal Monitoring Technologies |
Yes |
