Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
  • Intel Core i7-6820EQ processor 2.8 GHz 8 MB Smart Cache
The 6th generation Intel® Core™ i7 processors deliver a new class of computing with a host of new features to power the next generation of laptops and 2 in 1 PCs. Expect lighting fast speeds and peak performance through even the toughest of tasks and games. The built-in revolutionary Intel® Hyper-Threading Technology allows each processor core to work on two tasks at the same time for smoother multitasking while Intel® Iris™ graphics delivers stunning 3D visuals and faster, more advanced video and photo editing. Game the way you want and push the boundaries with overclocking for your most demanding gaming needs. The ultimate in peak performance.



Ready. Wake. Create

From zero to power in a flash, the 6th generation Intel® Core™ processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.



Stunning Visual Experiences

With 6th generation Intel® Core™ processor Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.



Security You Can Trust

Worry-free and hassle-free security is yours. With facial recognition and True Key™ technology, getting you logged in and protected has never been easier or more secure.
Box N
Bus type DMI3
Component for notebook
CPU configuration (max) 1
Embedded options available Y
Enhanced Intel SpeedStep Technology Y
Execute Disable Bit Y
Graphics & IMC lithography 14 nm
Idle States Y
Intel 64 Y
Intel Enhanced Halt State Y
Intel Trusted Execution Technology Y
Intel TSX-NI Y
Intel Virtualization Technology for Directed I/O (VT-d) Y
Intel VT-x with Extended Page Tables (EPT) Y
Maximum internal memory 65536 MB
Maximum number of PCI Express lanes 16
On-board graphics adapter Y
On-board graphics adapter model Intel HD Graphics 530
PCI Express configurations 1x16,1x8+2x4,2x8
PCI Express slots version 3.0
Processor boost frequency 3.5 GHz
Processor cache 8192 KB
Processor code SR2DT
Processor codename Skylake
Processor cores 4
Processor family Intel Core i7-6xxx
Processor frequency 2.8 GHz
Processor lithography 14 nm
Processor model i7-6820EQ
Processor operating modes 64-bit
Processor socket BGA 1440
Processor threads 8
Product type 4
Stepping R0
Supported instruction sets AVX 2.0,SSE4.1,SSE4.2
System bus rate 8 GT/s
Thermal Design Power (TDP) 45 W
Thermal Monitoring Technologies Y
Tjunction 100 °C
Processor cache type Smart Cache
Maximum internal memory supported by processor 64 GB
Memory types supported by processor DDR3L-SDRAM,DDR4-SDRAM,LPDDR3-SDRAM
Memory clock speeds supported by processor 1600,1866,2133 MHz
Memory bandwidth supported by processor (max) 34.1 GB/s
Memory channels supported by processor Dual
ECC supported by processor N
Intel Virtualization Technology (VT-x) Y
Intel Clear Video Technology Y
Processor package size 42 x 28 mm
On-board graphics adapter outputs supported DVI,DisplayPort,Embedded DisplayPort (eDP),HDMI
On-board graphics adapter base frequency 350 Mhz
On-board graphics adapter dynamic frequency (max) 1000 MHz
Maximum on-board graphics adapter memory 64 GB
On-board graphics adapter maximum resolution (HDMI) 4096 x 2304 pixels
On-board graphics adapter maximum resolution (DisplayPort) 4096 x 2304 pixels
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel) 4096 x 2304 pixels
On-board graphics adapter DirectX version 12.0
On-board graphics adapter OpenGL version 4.4
Processor series Intel Core i7-6800 Mobile Series
Market segment EMB
Status Launched
On-board graphics adapter ID 0x191B
Video decoding Y
On-board graphics adapter 4K support Y
On-board graphics adapter refresh rate at maximum resolution (HDMI) 24 Hz
On-board graphics adapter refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel) 60 Hz
Intel Software Guard Extensions (Intel SGX) Y
Conflict Free processor Y
Product family 6th Generation Intel Core i7 Processors
Number of displays supported (on-board graphics) 3
Intel® vPro™ Technology Y
Intel® Wireless Display (Intel® WiDi) Y
Intel® Insider™ Y
Intel® Clear Video HD Technology (Intel® CVT HD) Y
Intel® AES New Instructions (Intel® AES-NI) Y
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) Y
Intel® Hyper Threading Technology (Intel® HT Technology) Y
Intel® Identity Protection Technology (Intel® IPT) Y
Intel® Secure Key Y
Intel® OS Guard Y
Intel® Turbo Boost Technology 2.0
Intel® Quick Sync Video Technology Y
Processor ARK ID 90426
Intel® InTru™ 3D Technology Y

Download

CL8066201939103.pdf

Intel i7-6820EQ Data Sheet

Download (3.51MB)

Intel i7-6820EQ

Intel® Core™ i7-6820EQ Processor
(8M Cache, up to 3.50 GHz)
Out of Stock
£344.52
Tax excluded
Reference: CL8066201939103
Quantity
