Intel® Transactional Synchronization Extensions New Instructions (Intel® TSX-NI) are a set of instructions focused on multi-threaded performance scaling. This technology helps make parallel operations more efficient via improved control of locks in software.
Intel® Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel® IPT provides a hardware-based proof of a unique user’s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel® IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel® IPT provides a hardware-based proof of a unique user’s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel® IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
| Box | N |
| Bus type | QPI |
| Component for | server/workstation |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Demand Based Switching | Y |
| Intel Enhanced Halt State | Y |
| Intel Flex Memory Access | N |
| Intel Trusted Execution Technology | Y |
| Intel TSX-NI | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Maximum internal memory | 524288 MB |
| Maximum number of PCI Express lanes | 48 |
| On-board graphics adapter | N |
| PCI Express configurations | 1x16,1x4,1x8 |
| PCI Express slots version | 3.0 |
| Physical Address Extension (PAE) | 46 bit |
| Processor boost frequency | 3.90 GHz |
| Processor cache | 8448 KB |
| Processor code | SR3LJ |
| Processor codename | Skylake |
| Processor cores | 4 |
| Processor family | Intel Xeon |
| Processor frequency | 3.60 GHz |
| Processor lithography | 14 nm |
| Processor model | W-2123 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 2066 |
| Processor threads | 8 |
| Product type | 4 |
| Scalability | 1S |
| Stepping | U0 |
| Supported instruction sets | AVX,AVX 2.0,AVX-512,SSE4.2 |
| Tcase | 65 °C |
| Thermal Design Power (TDP) | 120 W |
| Thermal Monitoring Technologies | Y |
| Maximum internal memory supported by processor | 512 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133,2400,2666 MHz |
| Memory bandwidth supported by processor (max) | 85.3 GB/s |
| Memory channels supported by processor | Quad |
| ECC supported by processor | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Processor package size | 45 x 52.5 mm |
| Status | Launched |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Conflict Free processor | Y |
| Product family | Intel Xeon Processors |
| Intel® vPro™ Technology | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Secure Key | Y |
| Intel® OS Guard | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Processor ARK ID | 125036 |
| Intel Turbo Boost Max Technology 3.0 | N |
| Intel® Optane™ Memory Ready | N |
| Cooler included | N |
| Intel® Speed Shift Technology | Y |
| Intel® Memory Protection Extensions (Intel® MPX) | Y |
| Intel® Device Protection Technology (Intel® DPT) with Boot Guard | Y |
Intel Intel® Xeon® Processor W-2123 (8.25M Cache, 3.60 GHz)
Intel® Xeon® Processor W-2123
(8.25M Cache, 3.60 GHz)
(8.25M Cache, 3.60 GHz)
£335.42
£279.52 Ex. VAT
