Performance without Compromise
The DWL-6610APE is an affordable, Unified Wireless AC1200 Access Point, enabling businesses of all sizes create the fastest wireless network possible. With a sleek and stylish design, the DWL-6610APE can be discreetly deployed anywhere.
Wireless AC 1200
Maximum combined wireless speed of 1200 Mbps.
Broadcast on 32 SSIDs Simultaneously
Supports up to 32 SSIDs, 16 per radio, including station isolation.
Dual Band
Supports both 2.4Ghz and 5Ghz bands simultaneously.
Unified Wireless
Access points can be managed by unified wireless controller.
Smart Design
The DWL-6610APE can be mounted easily onto any wall or ceiling without looking out of place in an office or home. Enclosed in a plenum-rated UL2043 certified housing, the DWL-6610APE adheres to strict fire codes for placement in air passageways.
Band Steering technology
With band steering, the DWL-6610APE detects whether or not the wireless client is dual-band capable, and if so, it pushes the client to connect to the less congested 5 Ghz band. It does this by actively blocking the client’s attempts to associate with the 2.4 Ghz network.
Versatility Built as standard
Whether you intend to use a single Access Point or roll out a large corporate network, the DWL-6610APE coupled with a D-Link Wireless Controller or Unified Switch makes managing your wireless network simple.
Secure and Green Design
The DWL-6610APE has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.
Fast Seamless Roaming
Combining the DWL-6610APE with a Unified Wireless Switch or Controller allows you to create a wireless network that enables people to move freely around a building without losing connectivity.
Management platforms
D-Link’s Unified Wireless Access Points can be managed using a D-Link Wireless Controller or Unified Switch.
DWL-6610APE Management platforms
Simultaneous Dual-Band
Supports up to 867 Mbps 2x2 MIMO for the 5Ghz band and up to 300Mbps 2x2 MIMO for the 2.4Ghz band
The DWL-6610APE is an affordable, Unified Wireless AC1200 Access Point, enabling businesses of all sizes create the fastest wireless network possible. With a sleek and stylish design, the DWL-6610APE can be discreetly deployed anywhere.
Wireless AC 1200
Maximum combined wireless speed of 1200 Mbps.
Broadcast on 32 SSIDs Simultaneously
Supports up to 32 SSIDs, 16 per radio, including station isolation.
Dual Band
Supports both 2.4Ghz and 5Ghz bands simultaneously.
Unified Wireless
Access points can be managed by unified wireless controller.
Smart Design
The DWL-6610APE can be mounted easily onto any wall or ceiling without looking out of place in an office or home. Enclosed in a plenum-rated UL2043 certified housing, the DWL-6610APE adheres to strict fire codes for placement in air passageways.
Band Steering technology
With band steering, the DWL-6610APE detects whether or not the wireless client is dual-band capable, and if so, it pushes the client to connect to the less congested 5 Ghz band. It does this by actively blocking the client’s attempts to associate with the 2.4 Ghz network.
Versatility Built as standard
Whether you intend to use a single Access Point or roll out a large corporate network, the DWL-6610APE coupled with a D-Link Wireless Controller or Unified Switch makes managing your wireless network simple.
Secure and Green Design
The DWL-6610APE has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.
Fast Seamless Roaming
Combining the DWL-6610APE with a Unified Wireless Switch or Controller allows you to create a wireless network that enables people to move freely around a building without losing connectivity.
Management platforms
D-Link’s Unified Wireless Access Points can be managed using a D-Link Wireless Controller or Unified Switch.
DWL-6610APE Management platforms
Simultaneous Dual-Band
Supports up to 867 Mbps 2x2 MIMO for the 5Ghz band and up to 300Mbps 2x2 MIMO for the 2.4Ghz band
| Antenna gain level (max) | 4 dBi |
| Antennas quantity | 4 |
| Certification | CE, FCC, IC, cUL+UL, LVD, RCM, NCC, BSMI, UL2043 |
| Channels quantity | 165 channels |
| Colour of product | White |
| Data transfer rate (max) | 1200 Mbit/s |
| DC-in jack | Y |
| Detachable antenna(s) | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4 - 2.4835, 5.15 - 5.85 GHz |
| Height | 39 mm |
| Housing material | Plastic |
| Internal | N |
| LED indicators | Y |
| MAC address filtering | Y |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q,IEEE 802.3af |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Placement | Table |
| Power consumption (max) | 10.2 W |
| Power over Ethernet (PoE) | Yes |
| Quality of Service (QoS) support | Y |
| Security algorithms | AES,HTTPS,SSH,SSID,TKIP,WPA,WPA-Enterprise,WPA2,WPA2-Enterprise |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -20 - 65 °C |
| VLAN support | Y |
| Web-based management | Y |
| Weight | 476 g |
| Width | 205 mm |
| 2.4 GHz | Y |
| 5 GHz | Y |
| Wi-Fi Multimedia (WMM)/(WME) | Y |
| Number of SSID support | 32 |
Specific References
- EAN13
- 0790069432590
D-Link DWL-6610APE
802.11b/g/n/ac/a, 2.4/5 GHz, 3/4 dBi, SSID, VLAN, WMM, PoE, 10/100/1000BASE-T LAN, 205 x 39 mm
£208.89
Tax excluded
802.11b/g/n/ac/a, 2.4/5 GHz, 3/4 dBi, SSID, VLAN, WMM, PoE, 10/100/1000BASE-T LAN, 205 x 39 mm
