AC input frequency | 50 - 60 Hz 50/60 Hz |
AC input voltage | 110 - 240 V 110 - 240 V |
Auto MDI/MDI-X | Y Yes |
Auto-sensing | Y Yes |
Basic switching RJ-45 Ethernet ports quantity | 24 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) Gigabit Ethernet (10/100/1000) |
Cable types supported | Cat5 Cat5 |
Cables included | AC AC |
Certification | CE Mark, FCC 15 A, IC A, RCM, CCC, VCCI, KC, CB, CE LVD |
Depth | 180 mm |
Heat dissipation | 37.96 BTU/h 37.96 BTU/h |
Height | 44 mm |
Housing material | Metal |
Input current | 1 A 1 A |
Jumbo frames support | Y Yes |
Latency (1 Gbps) | 4.7 µs 4.7 µs |
LED indicators | Activity,Link,Power,Speed Activity, Link, Power, Speed |
MAC address table | 8000 entries 8000 entries |
Manual | Y Yes |
Mean time between failures (MTBF) | 620798 h 620798 h |
Networking standards | IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Operating altitude | 0 - 3000 m 0 - 3000 m |
Operating relative humidity (H-H) | 0 - 90 % 0 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Packet buffer memory | 0.512 MB 0.512 MB |
Power consumption (max) | 11.1 W 11.1 W |
Power over Ethernet (PoE) | No No |
Power supply included | Y Yes |
Quality of Service (QoS) support | Y Yes |
Rack mounting | Yes Yes |
Storage relative humidity (H-H) | 0 - 95 % 0 - 95% |
Storage temperature (T-T) | -20 - 70 °C -20 - 70 °C |
Switch type | Unmanaged Unmanaged |
Switching capacity | 48 Gbit/s 48 Gbit/s |
Wall mountable | Y Yes |
Weight | 1.31 kg |
Width | 252 mm |
Jumbo frames | 9216 9216 |
Packet forwarding rate (1 Gbps) | 1448000 pps 1448000 pps |
Product colour | Black |
Fanless | Yes |
Harmonized System (HS) code | 85176990 |
