3G | Y Yes |
4G | Y Yes |
4G bands supported | 700,800,850,1900,2300,2600 MHz 700,800,850,1900,2300,2600 MHz |
AC adapter included | Y Yes |
Antenna connector type | TS9 TS9 |
Antenna type | External |
Antennas quantity | 2 2 |
Browser supported | Microsoft® Internet Explorer® 11 or higher, Microsoft Edge, Google Chrome® 55 or higher, Firefox® 45 or higher, Safari® 10 or higher Microsoft® Internet Explorer® 11 or higher, Microsoft Edge, Google Chrome® 55 or higher, Firefox® 45 or higher, Safari® 10 or higher |
Cables included | LAN (RJ-45) LAN (RJ-45) |
DC-in jack | Y Yes |
Depth | 206 mm |
Detachable antenna(s) | Y Yes |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 4 |
Ethernet LAN data rates | 10,100,1000 Mbit/s 10,100,1000 Mbit/s |
Flash memory | 512 MB 512 MB |
Height | 57.2 mm |
Internal memory | 512 MB 512 MB |
LED indicators | LAN,Power,USB,WAN,WLAN,WPS LAN, Power, USB, WAN, WLAN, WPS |
Linux operating systems supported | Y Yes |
Mac operating systems supported | Y Yes |
Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n |
On/off switch | Y Yes |
Power source type | DC |
Product type | Tabletop router Tabletop router |
Quick start guide | Y Yes |
Reset button | Y Yes |
Security algorithms | 128-bit AES,WPA3 128-bit AES, WPA3 |
USB 2.0 ports quantity | 1 1 |
USB port | Y Yes |
Web-based management | Y Yes |
Weight | 580 g |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Width | 295.8 mm |
Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Windows 10,Windows 2000,Windows 7,Windows 8,Windows Vista,Windows XP |
WPS push button | Y Yes |
Memory card slot(s) | N No |
Ethernet LAN interface type | Gigabit Ethernet Gigabit Ethernet |
WAN connection type | RJ-45 RJ-45 |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) Wi-Fi 6 (802.11ax) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) Dual-band (2.4 GHz / 5 GHz) |
Product colour | Black |
WLAN data transfer rate (first band) | 600 Mbit/s |
WLAN data transfer rate (second band) | 1200 Mbit/s |
Antenna included | Yes |
USB sharing | Yes |
4G LTE category | 6 |
Mobile network generation | 4G |
Harmonized System (HS) code | 85176990 |
Antenna design | External |
