TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
  • TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch
Increase Your Network Speed and Save Energy



Let LiteWave Bring You Lighter Network Life

The TP-Link LiteWave Series Unmanaged Switches provide easy and affordable way to expand your wired network. They are easy to use and reliable. With these plug-and-play switches, you can expand your network connections to multiple devices instantly. With all ports support Auto-MDI/MDIX, there’s no need to worry about the type of cable to use.



Go Green with Your Ethernet

The LiteWave Series also supports energy-efficient technology, helping you save power and money. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!



Durable Metal Casing

The interior components of LS105G are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, LS105G delivers switching performance you can depend on. Its compact size makes it ideal for deployment on desktops or work benches.



Use Where You Need, However You Need

The LS105G is fully compatible with networked devices such as computers, printers, webcams, IPTVs. It has a wide range of application scenarios and is suitable for networking in school dormitories, surveillance, homes, and small businesses.
10G supportN
Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
CertificationCE, FCC, RoHS
Depth98 mm
Forwarding rate7.4 mpps
Heat dissipation9.466 BTU/h
Height25.1 mm
Jumbo frames supportY
LED indicatorsLAN,Power
MAC address table2000 entries
Networking standardsIEEE 802.1p,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
Operating relative humidity (H-H)10 - 90 %
Operating temperature (T-T)0 - 40 °C
Package depth125 mm
Package height92 mm
Package width128 mm
Packet buffer memory1 MB
Power consumption (max)2.776 W
Power over Ethernet (PoE)N
Power supply includedY
Quality of Service (QoS) supportY
Quick start guideY
Rack mountingN
Storage relative humidity (H-H)5 - 90 %
Storage temperature (T-T)-40 - 70 °C
Switch typeUnmanaged
Switching capacity10 Gbit/s
Width99.8 mm
Jumbo frames16
Product colourBlue

ls105g.pdf

TP-LINK 5-Port 10/100/1000Mbps Desktop Network Switch Data Sheet

Download (936.34k)
