P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
  • P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
  • P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
  • P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
  • P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
  • P-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+
Reasons to Buy
  • 8× Gigabit 802.3at/af-compliant PoE+ RJ45 ports
  • 1× Gigabit RJ45 port, 1× Gigabit SFP/RJ45 Combo port
  • 123W Power Budget, with up to 30W for each PoE port
  • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
  • Centralized Cloud Management via the web or the Omada app
  • Up to 250m PoE, QoS, PoE Auto Recovery, and Port Isolation for reliable surveillance networking
  • Automatic Loop Prevention, VLAN, and IGMP Snooping
  • Fanless design for silent operation
  • Durable metal casing and desktop/wall mounting design


Technical Headlines
  • Managed
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 10
  • MAC address table: 8000 entries Switching capacity: 20 Gbit/s
  • DC Power supply included Power over Ethernet (PoE)


Omada 10-Port Gigabit Easy Managed
Switch with 8-Port PoE+

Omada Cloud Essentials - A Free and Easy Cloud-Based Network Mnagement
Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system§, covering access points, switches, and gateways. It enables simple, centralized network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.

- Lifetime Free Cloud without Any Additional Fees
- Exists Entirely in the Cloud. No Hardware or Software Controller Needed
- Cloud Centralized Management for Multiple Sites
- Access Anytime via Omada App or Web
- Easy Setup, Use, and Maintenance
- Unlimited Management Scale
- Zero-Touch Provisioning (ZTP) without Unboxing
- Upgrade to Standard with a Seamless Subscription
10G support No
Auto MDI/MDI-X Yes
Auto-negotiation Yes
Basic switching RJ-45 Ethernet ports quantity 10
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Cables included AC
Combo SFP ports quantity 1
DC input voltage 53.5 V
Depth 126 mm
Flow control support Yes
Forwarding rate 14.88 Mpps
Height 26 mm
IGMP snooping Yes
Input current 2.43 A
Jumbo frames support Yes
Link aggregation Yes
MAC address table 8000 entries
Networking standards IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Package type Box
Packet buffer memory 4 MB
Port mirroring Yes
Power over Ethernet (PoE) Yes
Power over Ethernet plus (PoE+) ports quantity 8
Power source DC
Power supply included Yes
Quality of Service (QoS) support Yes
Reset button Yes
Source data-sheet Icecat.biz
Storage relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 70 °C
Store-and-forward Yes
Switch type Managed
Switching capacity 20 Gbit/s
Total Power over Ethernet (PoE) budget 123 W
Transmission distance (max) 0.25 km
User guide Yes
VLAN support Yes
Wall mountable Yes
Width 209 mm
Jumbo frames 15
Power over Ethernet (PoE) power per port 30 W
Product colour Black
Virtual LAN features MTU VLAN, Port-based VLAN, Tagged VLAN
DHCP features DHCP client
Fanless Yes
Cloud-managed Yes
Compliance certificates CE, Federal Communications Commission (FCC), RoHS

Specific References

EAN13
0810142820448

ES210GMP.pdf

TP-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+ Data Sheet

TP-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+

TP-Link Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable
In Stock
£116.67
£97.23 Ex. VAT
Reference: ES210GMP
