Origin Storage Ltd manufactures a full range of Quality Matched Hard Drive Solutions for most major Branded Servers, Notebooks and Desktops, such as Dell, Compaq, HP, Toshiba, and IBM. All Quality Matched Drive Solutions come with 3 years advanced replacement warranty and also come with free pre and post sales technical support. We can supply replacements or upgrades in form factors, 2.5" to 3.5" connectivity's including IDE, SATA, SAS and SCSI and of course in all available capacities and spin speeds. To find the perfect match for your computer why not click on the link to our configurator.
| Average latency | 2 ms |
| Bytes per sector | 512 |
| Compatible products | HP/Compaq ProLiant DL160 G6, ML150 G6, ML330 G6 |
| Component for | server/workstation |
| Depth | 146.52 mm |
| Height | 25.4 mm |
| Hot-swap | N |
| Interface | SAS |
| Internal | Y |
| Mean time between failures (MTBF) | 1600000 h |
| Non-operating altitude | -304.8 - 12192 m |
| Non-operating shock | 300 g |
| Non-operating vibration | 3 g |
| Operating altitude | -304.8 - 3048 m |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating shock | 60 g |
| Operating temperature (T-T) | 5 - 55 °C |
| Operating vibration | 1 g |
| Operating voltage | 5 / 12 V |
| Power consumption (idle) | 8.74 W |
| Power consumption (typical) | 12.92 W |
| RoHS compliance | Y |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Type | HDD |
| USB powered | N |
| Weight | 671 g |
| Width | 101.6 mm |
| Storage drive adapter included | N |
| Refurbished | N |
| Product colour | Black |
| HDD capacity | 146 GB |
| HDD speed | 15000 RPM |
| HDD size | 3.5 " |
| Storage drive buffer size | 16 MB |
| HDD interface transfer rate | 6 Gbit/s |
| HDD caddy included | N |
| HDD number of heads | 4 |
| Read seek time | 3.4 ms |
| Write seek time | 3.9 ms |
Specific References
- EAN13
- 5055146565154
Origin Storage 146GB 15k 3.5in SAS HP DLxxx MLxxx Series
146GB 15k 8.89 cm (3.5") SAS HP DLxxx MLxxx Series
£217.52
£181.26 Ex. VAT
146GB 15k 8.89 cm (3.5") SAS HP DLxxx MLxxx Series
