Switch and meter outlets & IT equipment across A and B feed: Combines both Switched and Metered Outlet functionality together in 1 ePDU

ePDU G3 Managed models allow complete lights-out control and metering of devices including devices powered across multiple ePDUs. They include IEC Class 1 (±1%) billing grade accuracy, an advanced hot-swap meter with LCD pixel display showing V, W, A and kWh, and the ability to daisy chain 8 ePDUs to share the same network connection and IP address.
AC outlet typesC13 coupler,C19 coupler
AC outlets quantity24 AC outlet(s)
Cable length3 m
Colour of productBlack
Dimensions (WxDxH)53 x 1604 x 52 mm
Input frequency50 Hz
LED indicatorsYes
Maximum current32 A
Nominal input voltage230 V
Operating temperature (T-T)0 - 60 °C
PDU typesMetered,Switched
Power plugIEC 60309
Rack mounting0U
RoHS complianceYes


Eaton EMAB18 Data Sheet

Download (1.27M)

Similar products

  • Eaton EMIB04
    Eaton EMIB04
  • Eaton EMIB03
    Eaton EMIB03
  • Eaton EMIB00
    Eaton EMIB00
  • Eaton EBAB22
    Eaton EBAB22
  • Eaton EBAB19
    Eaton EBAB19

Eaton EMAB18

ePDU G3 Managed, 7kW, 230V In, IEC 60309 (32A, Single-phase) In, 20x C13 Out, 2x C19 Out, 2x DIN Out


Out of Stock

£1,167.61 Ex VAT.
