D-Link DWL-8620APE wireless access point 2533 Mbit/s Power over Ethernet (PoE) White
  • D-Link DWL-8620APE wireless access point 2533 Mbit/s Power over Ethernet (PoE) White
  • D-Link DWL-8620APE wireless access point 2533 Mbit/s Power over Ethernet (PoE) White
  • D-Link DWL-8620APE wireless access point 2533 Mbit/s Power over Ethernet (PoE) White
  • D-Link DWL-8620APE wireless access point 2533 Mbit/s Power over Ethernet (PoE) White
The DWL Series Unified AC Wave 2 Wireless Access Points leverage the full potential of 802.11ac Wave 2 to provide unparalleled connectivity with ultra-high combined data rates. The DWL-8620AP and DWL-8620APE offer a faster combined speed of up to 2,533 Mbps. In addition, the DWL Series supports Link Aggregation3, which allows two Gigabit Ethernet ports to be linked together and act as a single port to double the available bandwidth and maximize the overall throughput of the access point.
Antennas quantity 4
Certification CE; EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60601-1-2, EN301489-1, EN301489-17, EN300328, EN301893; FCC; IC; cUL+UL; CB; RCM; NCC; BSMI;
Channels quantity 165 channels
DC-in jack Y
Depth 220 mm
Ethernet LAN (RJ-45) ports 2
Ethernet LAN data rates 10,100,1000 Mbit/s
Height 47 mm
Internal N
MAC address filtering Y
Management protocols SNMP v1/v2c/v3
Maximum data transfer rate 2533 Mbit/s
Mean time between failures (MTBF) 460185 h
Networking standards IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11k,IEEE 802.11n,IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3u
Operating relative humidity (H-H) 10 - 90 %
Operating temperature (T-T) 0 - 40 °C
Output current 2.5 A
Output voltage 12 V
Package depth 296 mm
Package height 94 mm
Package weight 1500 g
Package width 295 mm
Placement Ceiling,Wall
Power consumption (max) 24.24 W
Power over Ethernet (PoE) Yes
Quality of Service (QoS) support Y
Reset button Y
Security algorithms AES,TKIP,WPA,WPA-Enterprise,WPA2,WPA2-Enterprise
Storage relative humidity (H-H) 5 - 95 %
Storage temperature (T-T) -20 - 65 °C
VLAN support Y
Web-based management Y
Weight 920 g
Width 220 mm
2.4 GHz Y
5 GHz Y
Wi-Fi Multimedia (WMM)/(WME) Y
Auto Wireless Distribution System (WDS) Y
Pallet width 1200 mm
Pallet length 1100 mm
Automatic channel selection Y
MIMO Y
Product colour White
Band Steering Y
Airtime Fairness (ATF) Y
Shipping (inner) case width 312 mm
Shipping (inner) case length 449 mm
Shipping (inner) case height 328 mm
Number of SSID supported 32
Shipping (inner) case net weight 7500 g
Quantity per shipping (inner) case 5 pc(s)
Shipping (inner) case gross weight 8365 g
Pallet gross weight (air) 226260 g
Number of cartons per pallet (air) 24
Quantity per pallet (air) 120 pc(s)
Pallet height (air) 1447 mm
Pallet gross weight (sea) 276950 g
Number of cartons per pallet (sea) 30
Quantity per pallet (sea) 150 pc(s)
Pallet height (sea) 1775 mm

Specific References

EAN13
0790069441417

Download

dwl-8620ape.pdf

D-Link DWL-8620APE Data Sheet

Download (4.18MB)

D-Link DWL-8620APE

Wireless AC2600 Wave2 4X4 MU-MIMO Dual Band Unified Access Point with External Antennas
Out of Stock
£371.10
Tax included
Reference: DWL-8620APE
Quantity
