Basic ruggedized wireless
Cloud management, easy to deploy, integrated omni-directional antennas
Ideal use cases
- Basic outdoor or ruggedized wireless LANs
- Low-density deployments
- Connectivity for rural areas, garages, municipal athletic fields, rapid-response emergency kits
Guest access
- 1-click secure guest access
- Guest isolation firewall
- Customizable splash pages
- Integrated Facebook and Google login
- Cisco ISE integration for guest access and BYOD posturing
Layer 7 traffic shaping
- Classifies hundreds of applications
- Create per-application bandwidth limits
- Prioritize productivity apps
- Restrict or block recreational traffic
Device management
- Create device-specific firewall rules
- Monitor and track device inventory
- Deploy applications and enforce security settings
- Enterprise Mobility Management (EMM) and Mobility Device Management (MDM) integration
Cloud management
- Network-wide visibility and control
- Integrated analytics, reporting, and anomaly detection across networks
- Self-provisioning for rapid deployment
- Seamless firmware updates
- Redundancy and security built into cloud architecture
Analytics
Location analytics: measure visitor capture rate, visit length, and repeat visit rate over time and across sites
Global L7 traffic analytics reporting per device, network, and application
Enterprise security
- 802.1X and native Active Directory integration
- Stateful Layer 3-7 firewall
- Identity-based group policies
- Built-in antivirus scan (NAC)
Antenna gain level (max) |
4.7 dBi |
Antennas quantity |
2 |
Bandwidth |
5 GHz |
Certification |
UL, IEC, FCC, RoHS |
Channel bandwidth |
40 MHz |
Channels quantity |
2 channels |
Data transfer rate (max) |
1300 Mbit/s |
Depth |
30 mm |
Ethernet LAN (RJ-45) ports |
1 |
Ethernet LAN data rates |
100,1000 Mbit/s |
Height |
245 mm |
Integrated antenna |
Y |
Internal |
N |
International Protection (IP) code |
IP67 |
LED indicators |
Power |
Modulation |
256-QAM |
Mounting kit |
Y |
Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.11r,IEEE 802.3af |
Operating relative humidity (H-H) |
-20 - 55 % |
Placement |
Floor,Table,Wall |
Power consumption (max) |
11 W |
Power over Ethernet (PoE) |
Yes |
Security algorithms |
WEP,WPA,WPA2-Enterprise,WPA2-PSK |
Weight |
450 g |
Wi-Fi data rate (max) |
54 Mbit/s |
Width |
115 mm |
2.4 GHz |
Y |
5 GHz |
Y |
Wi-Fi Multimedia (WMM)/(WME) |
Y |
Tagged VLAN |
Y |
MIMO |
Y |
MIMO type |
Multi User MIMO |
Product colour |
White |
Maximal-Ratio Combining (MRC) |
Y |
Wi-Fi Roaming |
Y |
Wireless Intrusion Detection System (WIDS) |
Y |
