Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
LED status indicators
Quickly understand unit and power status with visual indicators.
AC outlet types |
C13 coupler |
AC outlets quantity |
4 |
Audible alarms |
Yes |
Cable length |
1.82 m |
Colour of product |
Black |
Input operation voltage (max) |
280 V |
Input operation voltage (min) |
160 V |
LED indicators |
Status |
Noise level |
45 dB |
Operating relative humidity (H-H) |
0 - 95 % |
Operating temperature (T-T) |
0 - 40 °C |
Output operation voltage (max) |
230 V |
Output operation voltage (min) |
230 V |
Output power |
300 W |
Output power capacity (VA) |
500 VA |
Power supply input frequency |
45/65 Hz |
RoHS compliance |
Yes |
Storage relative humidity (H-H) |
0 - 95 % |
Storage temperature (T-T) |
-15 - 45 °C |
Surge energy rating |
273 J |
Weight |
5200 g |
Width |
115 mm |
Specific References
- EAN13
- 7313043073652
