Battery recharge time | 2.5 h |
Battery technology | Sealed Lead Acid (VRLA) |
Cable length | 3.05 m |
Certification | CSA,FCC Part 15 Class A,UL 1778 |
Colour of product | Black |
Dimensions (WxDxH) | 130 x 660 x 432 mm |
Input connection type | NEMA L5-30P |
Interface | DB-9 RS-232, Smart-Slot |
LED indicators | Yes |
Noise level | 55 dB |
Nominal input voltage | 120 V |
Non-operating altitude | 0 - 15000 m |
Operating altitude | 0 - 3000 m |
Operating relative humidity range | 0 - 95 % |
Operating temperature range (T-T) | 0 - 40 °C |
Output connections | (6) NEMA 5-15R, (2) NEMA 5-20R |
Output power | 2100 W |
Output power capacity (VA) | 3000 VA |
Package dimensions (WxDxH) | 603 x 980 x 347 mm |
Package weight | 63.64 kg |
Power supply input frequency | 50/60 Hz |
Replacement battery cartridge | RBC44 |
Storage relative humidity range | 0 - 95 % |
Storage temperature range (T-T) | -15 - 45 °C |
Surge energy rating | 480 J |
Typical backup time at full load | 14.1 min |
Typical backup time at half load | 33.9 min |
Weight | 54.55 kg |
