Top and bottom cable entry (standard)
Flexibility that allows the customer to decide - and at no extra cost.
Multiple distribution options
Superior design flexibility enables a wide range of customer requirements to be addressed.
Remote Management Capabilities
Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.
Colour of product |
Black |
Dimensions (WxDxH) |
610 x 914 x 2159 mm |
Input frequency |
50/60 Hz |
Maximum input current per phase |
100 A |
Operating relative humidity range |
0 - 95 % |
Operating temperature range (T-T) |
0 - 40 °C |
Package dimensions (WxDxH) |
813 x 1219 x 2286 mm |
Package weight |
227.28 kg |
Storage relative humidity range |
0 - 95 % |
Storage temperature range (T-T) |
-15 - 45 °C |
Weight |
204.56 kg |
Specific References
- EAN13
- 0731304207894
