Availability
Predictable cooling
Placing the unit in the row of racks moves the source of cooling closer to the heat load. This eliminates air mixing and provides a predictable cooling architecture.
Rack Inlet Temperature Control
Reduces the risk of hot spots at the rack level
Active response controls
Monitors and actively adjusts cooling capacity to ensure proper server inlet temperatures. Through the microprocessor controller, visibility into the operation and health of the unit is provided.
Total Cost of Ownership
Variable speed fans
Variable speed fans reduce energy consumption during off-peak cooling periods.
In-Row architecture
Captures hot exhaust air directly from the IT equipment, thereby increasing the unit's sensible cooling capacity over traditional cooling architectures.
AC input frequency |
50 Hz |
AC input voltage |
400 V |
Airflow |
4600 CFM |
Certification |
cUL Listed, CE, Industry Canada, UL Listed, VDE |
Colour of product |
Black |
Coupling type |
R407C |
Dimensions (WxDxH) |
600 x 1070 x 1991 mm |
Electrical input connection |
Hard Wire 4-wire (3PH + G) |
Package dimensions (WxDxH) |
850 x 1137 x 2166 mm |
Package weight |
429550 g |
Rack mounting |
42u |
Type |
Freestanding |
Weight |
367270 g |
Specific References
- EAN13
- 0731304262572
