Allied Telesis AT-2911SX/LC-901 | Allied Telesis Network Cards & Adapters | Netstore Direct
  • Allied Telesis AT-2911SX/LC-901 | Allied Telesis Network Cards & Adapters | Netstore Direct
  • Allied Telesis AT-2911SX/LC-901 | Allied Telesis Network Cards & Adapters | Netstore Direct
  • Allied Telesis AT-2911SX/LC-901 | Allied Telesis Network Cards & Adapters | Netstore Direct
Allied Telesis AT-2911 Series Network Interface Cards feature a PCI Express (PCIe x1) design, providing the maximum possible bandwidth and bus efficiency while providing the benefits of low power consumption.



High Reliability

The AT-2911 Series Gigabit interface comes with a comprehensive Microsoft Windows utility which performs detailed tests, diagnostics and analysis.



Advanced Manageability

The priority queuing offered by the AT-2911 Series can help users set up the network based on their own needs. The comprehensive diagnostics and configuration software suite provides system administrators and engineers with a profound tool to analyze the interface card and check specific data.
Certification UL
FCC/EN55022 A
TUV
EN55024
CE
C-TICK
VCCI
Connectivity technology Wired
Data transfer rate (max) 1000 Mbit/s
Fiber ethernet cabling technology 1000BASE‑SX
Fiber optic connector LC
Fiber ports quantity 1
Flow control support Y
Height 56 mm
Host interface PCI-E
Input voltage 3.3 V
Interface fiber
Internal Y
Jumbo frames support Y
LED indicators Y
Link/Act LED Y
Linux operating systems supported Y
Management protocols SNMP
Networking standards IEEE 802.1p,IEEE 802.1Q,IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Operating relative humidity (H-H) 5 - 90 %
Operating temperature (T-T) 0 - 40 °C
Power consumption (typical) 9.2 W
RoHS compliance Y
Source data-sheet Icecat.biz
Storage temperature (T-T) -25 - 70 °C
Weight VFD and cable: 36.6 lb; Pole (each): 50.7 oz; Base: 66.1 lb (VFD and cable: 1.29 lb; Pole (each): 1.79 oz; Base: 2.33 lb)
Width 87 mm
Windows operating systems supported Y

AT-2911SXLC-901.pdf

Allied Telesis AT-2911SX/LC-901 Data Sheet

Allied Telesis AT-2911SX/LC-901

1000BASE-SX Single-port Fiber NIC for PCIe x1 bus, LC connector, Federal/Government
In Stock
£237.96
£198.30 Ex. VAT
Reference: AT-2911SX/LC-901
Quantity
