Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
  • Ubiquiti Networks NanoBeam 5AC Gen 2 Network bridge 450Mbit/s White
Incorporating innovative industrial design with proprietary airMAX® ac technology, the NanoBeam® AC is ideal for CPE deployments requiring maximum performance from the smallest possible footprint.



Management Wi-Fi Radio

The NanoBeam® AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.



Improved Surge Protection

The NanoBeam® AC features enhanced protection against ESD events.



Superior Processing

Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.



Incredible Antenna “Beam” Performance

The form factor of the NanoBeam® AC features the highest gain for its size. The NanoBeam AC’s excellent beam directivity provides the best performance in high-noise environments.



Performance Breakthrough

airMAX® ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.



Advanced Software Technology

Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.



Plug and Play Installation

The NanoBeam® AC mounts to a variety of surfaces including poles or walls, and offers the freedom of three-axis alignment. No screws are required for pole-mounting, and only a single wall screw (not included) is required for wall-mounting.



Now with airOS®8

airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
Antenna gain level (max) 19 dBi
Certification CE, FCC, IC, RoHS
Colour of product White
Data transfer rate (max) 450 Mbit/s
Dimensions (WxDxH) 189 x 189 x 125 mm
Ethernet LAN Y
Ethernet LAN (RJ-45) ports 1
Frequency band 2.412 - 2.472, 5.15 - 5.875; 5.15 - 5.25; 5.25 - 5.35; 5.47 - 5.725; 5.725 - 5.85 GHz
Internal memory 128 MB
LED indicators LAN,Power,Signal strength
Modulation 16-QAM,64-QAM,256-QAM,BPSK,QPSK
Operating relative humidity (H-H) 5 - 95 %
Operating temperature (T-T) -40 - 176 °F
Product type Network bridge
Security algorithms WPA2
Web-based management Y
Weight 530 g

Specific References

EAN13
0810354026348

NBE-5AC-GEN2.pdf

Ubiquiti Networks NanoBeam 5AC Gen 2 Data Sheet

NBE-5AC-GEN2.pdf

Ubiquiti Networks NanoBeam 5AC Gen 2 Data Sheet

Ubiquiti Networks NanoBeam 5AC Gen 2

5 Ghz, 450 Mbps, 19 dBi, 10/100/1000 Ethernet, 128 MB DDR2, 8 MB Flash, 1.5:1 VSWR, 189 x 189 x 125 mm
In Stock
£111.91
£93.26 Ex. VAT
Reference: NBE-5AC-GEN2
Quantity
