StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
  • StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable
This compact M.2 SATA SSD enclosure lets you add highly portable data storage to any laptop or computer with a USB-C™ port - such as MacBook, Chromebook Pixel™, Dell™ XPS laptops, and many others. It turns your SATA M.2 drive into a high-speed storage solution over a USB 3.1 Gen 2 connection, at up to 10Gbps throughput.



A truly portable solution

This slim, pocket-sized enclosure for M.2 NGFF SATA SSDs has been specially designed for mobility, with a small form factor design that fits easily into your laptop bag. Its lightweight yet durable aluminum housing helps to ensure your drive won’t be damaged while you’re on the move.



Ventilation holes help to dissipate heat and help ensure an optimum operating temperature.



Maximize the performance of your M.2 SATA SSD

Leverage the speed of your M.2 NGFF SATA drive with this external enclosure. It delivers USB 3.1 Gen 2 data transfer speeds up to 10Gbps as well as UASP support, so you can achieve higher transfer speeds when you connect it to a UASP-enabled host computer.



The enclosure works with tablets, laptops and desktop computers and is compatible with hosts equipped with Thunderbolt 3 USB-C ports.



Broad compatibility

The enclosure is compatible with all of the common M.2 SATA SSDs, and enables you to mount multiple drive lengths, including: 30mm (2230), 42mm (2242), 60mm (2260), and 80mm (2280).



The SM21BMU31C3 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Cables includedUSB
CertificationCE, FCC
ChipsetASMedia - ASM1351
Colour of productBlack,Silver
Data transfer rate10 Gbit/s
Depth99 mm
Height13 mm
Integrated USB cableNo
LED indicatorsActivity,Power
MaterialAluminium
Mean time between failures (MTBF)1000000 h
Number of storage drives supported1
Operating relative humidity (H-H)10 - 90 %
Operating temperature (T-T)0 - 40 °C
Package depth160 mm
Package height30 mm
Package weight132 g
Package width130 mm
Power source typeUSB
Product typeSSD enclosure
Quick installation guideYes
RoHS complianceYes
Screws includedYes
Storage relative humidity (H-H)5 - 95 %
Storage temperature (T-T)-10 - 65 °C
Supported storage drive interfacesM.2
UASP supportYes
USB connectivityYes
USB connector genderFemale
USB connector typeMicro-USB B
USB ports quantity1
USB version3.1 (3.1 Gen 2)
Weight48 g
Width42 mm
Screwdriver includedYes
Supported storage drive lengths80 mm

SM21BMU31C3.pdf

StarTech.com M.2 NGFF SATA Enclosure - USB 3.1 (10Gbps) with USB-C Cable Data Sheet

Download (153.88k)
