Lenovo X722
  • Lenovo X722
  • Lenovo X722
  • Lenovo X722
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.



ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.



The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
CertificationUL recognized to UL60950-1 2nd Edition\nFCC Rules, Part 15, Class A\nAustralian EMC Framework (RCM)\nJapan VCCI, Class A\nIndustry Canada, ICES-003, Class A\nEU (CE Mark)\nKorea KC-RRA, Class A
ChipsetIntel C624
Colour of productGreen
Compatible productsSR630\nSR650\nSR850\nSR860\nSR950
Connectivity technologyWired
Data transfer rate (max)1000 Mbit/s
Ethernet LAN (RJ-45) ports4
Ethernet LAN data rates10,100,1000 Mbit/s
Flow control supportY
Host interfacePCI-E
InterfaceEthernet
InternalY
Jumbo frames supportY
Linux operating systems supportedRed Hat Enterprise Linux WS 6.0,Red Hat Enterprise Linux WS 7.0,openSUSE 11.3,openSUSE 11.4,openSUSE 12.1,openSUSE 12.2
Networking standardsIEEE 802.1Q,IEEE 802.1Qbg,IEEE 802.1p,IEEE 802.3ad,IEEE 802.3x
Number of VLANs4096
Other operating systems supportedVMware vSphere ESXi
PCI-SIG* SR-IOV CapableY
Quality of Service (QoS) supportY
Receive Side Scaling (RSS)Y
RoHS complianceY
Security algorithmsSNMP
Server operating systems supportedWindows Server 2012 R2,Windows Server 2012 R2 x64,Windows Server 2016
VLAN taggingY
Jumbo frames9728

Similar products

  • Lenovo 4XC0H00338
    Lenovo 4XC0H00338
  • Lenovo 00AG560
    Lenovo 00AG560
  • Lenovo 00AG580
    Lenovo 00AG580
  • Lenovo 01CV830
    Lenovo 01CV830
  • Lenovo 01CV840
    Lenovo 01CV840

Lenovo X722

ThinkSystem 1Gb 4-port RJ45 LOM

7ZT7A00545

In Stock

£129.73
£108.11 Ex VAT.
