ETGEAR GS748PP
  • ETGEAR GS748PP
  • ETGEAR GS748PP
  • ETGEAR GS748PP
  • ETGEAR GS748PP
  • ETGEAR GS748PP
  • ETGEAR GS748PP
Reasons to Buy
  • 48 x Gigabit Ethernet ports with 24 ports of PoE+
  • Plug and play switch, no management required
  • Energy Efficient Ethernet for maximum power savings
  • Dynamic fans for quiet operation
  • Rackmount or desktop


Technical Headlines
  • Unmanaged
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 48
  • 10BASE-T
  • MAC address table: 8000 entries
  • Rack mounting
  • AC/DC Power over Ethernet (PoE)


POWER-OVER-ETHERNET

24 PoE+ ports delivering up to 30W per port with a 380W total power budget for wireless APs, IP Cameras, IP Phones and much more. Dynamic PoE maximizes usage of PoE budget.

PLUG-AND-PLAY

Simple set up with no software to install or configuration needed

NON-BLOCKING SWITCHING

Non-blocking switching architecture for maximum throughput at wire speed

DYNAMIC FANS

Optimal balance between noise and performance.

VERSATILE MOUNTING OPTIONS

Install your switch on your desktop or mount it to your rack with the hardware provided in the box

ENERGY EFFICIENT

Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Authentication method 802.1x
Bandwidth 96 Gbit/s
Basic switching RJ-45 Ethernet ports quantity 48
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Connectivity technology Wired
Copper ethernet cabling technology 10BASE-T
Depth 310 mm
Electromagnetic emissions CE mark, FCC Part 15 Class A, VCCI Class A, C-Tick
Ethernet LAN data rates 1000 Mbit/s
Flow control support Yes
Full duplex Yes
Heat dissipation 34.2 BTU/h
Height 43 mm
I/O ports 48 x 10/100/1000 Mbps
4 x SFP
Input current 8 A
Jumbo frames support Yes
Latency 2,900ns
Link aggregation Yes
MAC address table 8000 entries
Maximum data transfer rate 1 Gbit/s
Mean time between failures (MTBF) 570972 h
MIB support RFC 1213 MIB II, RFC 1643, RFC 1493
Networking standards IEEE 802.1p, IEEE 802.3az
Number of fans 2 fan(s)
Operating altitude 0 - 3000 m
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 50 °C
Packet buffer memory 1.5 MB
Power consumption (max) 410 W
Power over Ethernet (PoE) Yes
Power source AC/DC
Quality of Service (QoS) support Yes
Rack mounting Yes
Redundant fans support Yes
Safety CE mark, cUL IEC950/EN60950
Source data-sheet Icecat.biz
Storage temperature (T-T) -20 - 70 °C
Switch type Unmanaged
Total Power over Ethernet (PoE) budget 380 W
Weight 4.6 kg
Width 440 mm
Jumbo frames 12.288
Power over Ethernet (PoE) power per port 30 W
Product colour Grey
Compliance certificates CB, CE, Federal Communications Commission (FCC), KC, Low Voltage Directive (LVD), RCM, UL, VCCI
Warranty period 2 year(s)

Specific References

EAN13
5715328108516

GS748PP-100EUS.pdf

NETGEAR GS748PP Data Sheet

NETGEAR GS748PP

NETGEAR GS748PP, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting
In Stock
£632.40
£527.00 Ex. VAT
Reference: GS748PP-100EUS
